Model NMA Lifting Clamp

Locking Type

The Model NMA is a non-marring clamp with smooth
gripping pads that can lift hard surface materials.
Materials with sensitive finishes such as stainless steel,
copper, aluminum and polished metal plates can also be
lifted. The clamp incorporates a locking feature which
enables the clamp gripping jaws to be “Locked Open”
for attaching and removing the clamp from the material
being lifted and to be “Locked Closed” for turning
material through 180 degrees. It is recommended these
clamps be used in pairs.

Rated Capacity Tons (each clamp)	Plate Thickness A	B	C	D	E	MAX. F	G	H	J
1/2	0-1/2	3 7/16	7 26/32	12 1/16	2	7 1/4	4 1/4	2 15/16	1/2
1	0-3/4	4 3/4	11 3/8	16 13/16	2 5/8	9 5/8	5 1/16	4 5/8	5/8
2	0-1	5 1/2	12 7/8	20 1/8	3	11 1/2	6	4 15/32	3/4
4	1/4-1 1/4	6 31/32	14 7/16	22 1/4	3 5/8	11 11/16	6	4 7/8	1
4	1-2	6 31/32	14 7/16	22 1/4	3 5/8	12 13/16	6	4 7/8	1
No operator should engage or attempt to engage in the use of any RENFROE® product until the applicable manual has been read and fully understood. Failure to review and utilize recommended applications, operating and maintenance instructions could result in serious injury to the operator and others. SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE. OTHER CAPACITIES AVAILABLE UPON REQUEST. (HOT LIFT) CLAMPS AVAILABLE- CALL FOR PARTS 866.392.2829

Part Number	Description	Brand	Weight	Price	Quantity
NMA-00.50-A	1/2 ton - Jaw Opening 0-1/2" Model NMA Lifting Clamp	J.C. Renfroe	16 lbs	$5716.00	+ -
NMA-01.00-A	1/2 ton - Jaw Opening 0-1/2" Model NMA Lifting Clamp	J.C. Renfroe	27 lbs	$6102.00	+ -
NMA-02.00-A	1/2 ton - Jaw Opening 0-1/2" Model NMA Lifting Clamp	J.C. Renfroe	53 lbs	$6695.00	+ -
NMA-04.00-A	1/2 ton - Jaw Opening 0-1/2" Model NMA Lifting Clamp	J.C. Renfroe	64 lbs	$8768.00	+ -
NMA-04.00-B	4 ton - Jaw Opening 1-2" Model NM Lifting Clamp	J.C. Renfroe	66 lbs	$10097.00	+ -

Model NMA Lifting Clamp
