Model RO Lifting Clamp

Name: Model RO Lifting Clamp
SKU: 2021052506
Availability: InStock

Price: Based on Selection Status: Call To Order - Toll Free 866.392.2829

Locking Type

The Model RO incorporates a “Lock Open Only” feature
allowing the clamp to be “Locked Open,” lifted onto a
“hot” plate and the lock released without the operator
coming in close contact with the “hot” plate.

Model RO Spec

SPECIFICATIONS (in inches)

Rated Capacity Tons	Plate Thickness A	B	C	D	E	F	G	Weight
35	1/4 - 4 1/4"	8 3/8	23 5/8	5 1/16	5	21 3/8	8	470
35	4 - 8"	8 3/8	23 5/8	5 1/16	5	25 1/8	8	515
50	1/2 - 6 1/2"	13	44 3/4	9	5	36	13 1/2	1370
50	6 - 12"	13	44 3/4	9	5	41 1/2	13 1/2	1500
75	1/2 - 6 1/2"	16 1/2	46 3/4	14 1/4	11	42 1/2	12 1/2	2700
	3 - 9"	16 1/2	46 3/4	14 1/4	11	45	12 1/2	2775
	6 - 12"	16 1/2	46 3/4	14 1/4	11	48	12 1/2	2850
	8 - 14"	16 1/2	46 3/4	14 1/4	11	50	12 1/2	2900
No operator should engage or attempt to engage in the use of any RENFROE® product until the applicable manual has been read and fully understood. Failure to review and utilize recommended applications, operating and maintenance instructions could result in serious injury to the operator and others. SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE. OTHER CAPACITIES AVAILABLE UPON REQUEST. CALL FOR PARTS 866.392.2829
